iOS Haptic

iOS Haptic on the Asset Store

Introduction

The iOS Haptic plugin allows you to easily add haptic feedback to your Unity iOS project using the Taptic Engine on supported devices (iPhone 7 and iPhone 7 Plus and newer iPhones).


The categories of haptic feedback exposed by the Taptic Engine API are:


• Physical impacts (3 types: light, medium, and heavy)
• UI Notification feedback (3 types: Success, Warning, and Error)
• UI Selection Change feedback (single type)

New in iOS 13:

• Transient and continuous haptic playback control
• Two new haptic parameters: intensity and sharpness


It is strongly advised that you read and understand Apple's Human Interface Guidelines for using the Taptic Engine before submitting your app to the App Store: https://developer.apple.com/ios/human-interface-guidelines/interaction/feedback/

Important: On-device testing

Use of the Taptic Engine will only work when the Unity project containing the plugin is deployed to a supported physical device. It will not work when the project is run in the Unity Editor with the Unity Remote 5 app, or in the Xcode simulator, or on an unsupported device.

Quick Start

You can begin adding haptics to your iOS game in just a few steps:

• Import the iOS Haptic asset to your Unity project
• Drag an instance of the iOSHapticController prefab into your scene.
• Trigger haptic feedback from your game scripts at any time with simple calls to the iOSHapticController singleton.

For example:

void Start() {
     // triggers a haptic feedback simulating an impact of medium size
     iOSHapticController.instance.TriggerImpactMedium();
}

The full scripting API reference is provided below.

API Definitions

A prefab controller, iOSHapticController, is provided with an example scene for reference which demonstrates how to trigger haptic feedback using UI Buttons. The controller's singleton class exposes the following functions, which are responsible for triggering feedback or managing the Taptic Engine’s generators:


Haptic Feedback

TriggerImpactLight() - simulates a light physical impact


TriggerImpactMedium() - simulates a medium physical impact


TriggerImpactHeavy() - simulates a heavy physical impact


TriggerNotificationSuccess() - a type of feedback that suggests an action has been performed successfully


TriggerNotificationWarning() - a type of feedback that suggests a warning to the user


TriggerNotificationError() - a type of feedback that suggests an error has occurred


TriggerSelectionChange() - a type of feedback that communicates that a selection made by the user has changed (example scene hooks into a horizontal slider's OnValueChanged method)


Managing the Haptic Generators

PrepareTapticEngine() - call this optional function in advance of triggering feedback in order to reduce latency (has no effect on latency if called immediately before triggering haptic feedback)


ReleaseHapticGenerators() - call this optional function if you no longer require the Taptic Engine


SetupHapticGenerators() - call this function if you've previously released the haptic generators and need to use the Taptic Engine again

For iOS 13+

PlayTransientHaptic(intensity, sharpness) - plays a one-shot haptic event with intensity and sharpness parameters

PlayContinuousHaptic(intensity, sharpness, time) - plays a continuous haptic event with intensity and sharpness parameters for a duration of time (maximum 30 seconds)

UpdateContinuousHaptic(intensity, sharpness) - updates a playing haptic event with new intensity and sharpness values

StopHaptic() - stops the currently playing haptic event
